Acta Scientific Medical Sciences

Case Report Volume 8 Issue 9

Infiltration of the Root Canal Obturation Due to Deficient Composite Restoration

Elena Zabrac1*, Luiza Nicolcea1, Ruxandra Bartok2, Dan Alexandru Straja1, Cristina Coralia Nistor3

1PhD Student at University of Medicine and Pharmacy "Carol Davila" Bucharest, Romania
2Department of Esthetic Dentistry, University of Medicine and Pharmacy “Carol
Davila” Bucharest, Romania
3Department of Endodontics, Faculty of Dental Medicine, “Carol Davila” University of Medicine and Pharmacy, Bucharest

*Corresponding Author: Dan Alexandru Straja and Ruxandra Bartok, PhD Student at University of Medicine and Pharmacy "Carol Davila" and Department of Esthetic Dentistry, University of Medicine and Pharmacy “Carol Davila” Bucharest, Romania.

Received: June 26, 2024; Published: August 08, 2024

Citation: Dan Alexandru Straja and Ruxandra Bartok., et al. “Infiltration of the Root Canal Obturation Due to Deficient Composite Restoration ”. Acta Scientific Medical Sciences 8.9 (2024): 57-62.

Abstract

The aim of this study is to demonstrate the significance of carrying out a proper, well-adapted coronal restoration in order to prevent bacterial infiltration of the root canal sealing. We studied 49 clinical cases endodontically pretreated, with occluso-proximal restorations placed. We selected to present 10 clinical cases that had incorrect coronal obturation, which allowed contamination of the root canal treatment. Incorrect marginal adaptated restorations with composite resin and, also the fissures/fractures of the composite material or dental structure, the appearance of secondary caries, and marginal discolouration, can cause infiltration of the root canal filling.

We must highlight the fact that the quality of the root canal treatment also depends on the correct type of coronal restoration chosen (direct or indirect restorations).

Keywords: Root Canal Obturation; Deficient Composite Restorations; Periapical Pathology

Introduction

A good quality coronal restoration prevents corono-apical infiltration. Bacterial penetration into the root canal does not occur in case of a correctly restored access cavities. Teeth with adequate restoration have a low prevalence of apical periodontitis [1].

Currently, light-curing composite resins are the filling materials of choice used for direct frontal and lateral restorations.

The quality of composite resin restorations can be considered the key to long-term success, along with correct endodontic treatment.

Of course, in this sense, an integrative approach is needed both to the desired aesthetic and to the correct occlusal relationships, but what we wanted to highlight is the fact that the importance of a completed coronal restoration in our study, from composite resins, must offers the guarantee of an obturation that ensures the absence of marginal infiltration, which can be the causal factor of compromising the quality of the root canal treatment [2-5].

In order to achieve a correct root canal treatment, it must be followed in the shortest possible time by a correct restoration of the endodontic access cavity and possibly other deep cavities in the respective tooth.

Studies have shown that endodontically treated teeth have a higher risk of fractures than vital, unrestored teeth [6-8], caused by the loss of dental structure. Correct cuspal covering restoration (direct composite restoration or cast restoration) placement can lower the chances of fracture [9-11].

Coronal composite resin restorations with deficiencies

The purpose of this study is to radiologically evaluate the quality of inadequate coronal restorations. We investigated 49 cases with inadequate class I and II coronal restorations applied to previously endodontically treated teeth. Of these, 9 cases were eliminated from the study because it was clinically established, after the removal of the coronal restoration with minimal deficiencies, that the quality of the root canal obturation was not affected.

The following images show suggestive retroalveolar radiographs with infiltrated root canal obturation after a coronal restoration with deficiency, either you find a complete or incomplete fracture in the composite segment that affects the depth of the cavity (both enamel and dentin) (figure 1, 2, 4, 6), or the fracture of a composite fragment that interests the edge of the cavity (figure 2, 3, 4, 5, 7, 8).

After the removal of the corono-proximal restorations, we used an endodontic probe to examine the root canal obturation and observed that sealing has been altered, suggesting that the root canal treatment has been compromised.

X-Rays of endodontically pretreated teeth with root canal obturation and deficient restorations (figure 1-8).

In this retroalveolar radiographs are presented teeth with deficient coronal restoration, compromising the root canal obturation by the infiltration of the sealer. It is necessary doing in the same session, the endodontic retreatment and reapplying the composite coronal restoration.

Figure 1, 2, 3, 4

Figure 1, 2, 3, 4

Figure 1, 2, 3, and 4, the teeth 24, 25, 14, 26 and 26, presented coronal fillings with deficiencies in the vertical direction, meaning the absence of material in the depth of the cavity. Therefore, the lack of tightness of the composite resin allows the infiltration of the root canal treatment.

Figure 5, 6, 7, 8

Figure 5, 6, 7, 8

In figure 5, 7 and 8, there are several improperly marginally adapted voluminous coronal fillings that show signs of secondary caries. Teeth 17, 26, and 16 need root canal retreatment and restore the abutment in the same session. Preparing the teeth for a dental crown.

In Figure 5, also a periodontal disease can be seen in the radiograph of tooth 17. It can be observed that the incorrect coronal restoration helped progress the marginal periodontitis.

Figure 6, tooth 16 does not have a coronal restoration, so the root canal treatment is exposed and can be easily infiltrated. Both the coronal obturation and the root canal retreatment must be completed in the same session.

Figure 9, 10

Figure 9, 10

In Figure 9, tooth 38 with a small distal fragment of the restoration fractured and infiltrated, due to the lack of adaptation of the dental crown. After removing the restoration material, we examined the root canal obturation using endodontic tools (Kerr files, endodontic probe) and decided to the endodontic retreatment.

At examination, the root canal sealing was soft and not adapted to the root canal walls.

Figure 10, tooth 38 with root canal retreatment finished and dental crown applied.

Figure 11, 12

Figure 11, 12

Figure 11, tooth 27 has a coronal composite restoration which shows a deficiency in the distal area as a result of the wall restoration fracturing. Also the root canal obturation is infiltrated. It is recommended to be done in one single appointment, the root canal retreatment and the composite coronal restoration.

Figure 12, tooth 27 with endodontic retreament and coronal obturation finalised.

Discussions

The success of endodontic therapy is determined by the decontamination and complete obturation of the root canal system, and also by the correct coronal restoration [12].

Endodontic failures are typically caused by inadequate coronal sealing (microleakage), bacteria present in the the root canal system and iatrogenic errors (i.e., inadequate access cavity preparation) [13].

The success of the endodontic therapy depends also on the crown restoration of the endodontically treated tooth being completed în the same session.

The lack of tooth substance with small dehiscent areas, and the radiological image is much more relevant and betrays a maladaptation of the restorative material, which we can assume has determined, in addition to coronal microleakage, also the presence of bacteria at the root canal level, compromising its quality.

Following photopolymerization, the composite resins experience a thermal contraction at the restoration margins, or the tooth-composite material interface, leading to voids and microleakage [14]. Any bonded restorative’s adaptability is mostly determined by the cavity’s form and the number of bonded walls with proper adhesive system [14].

While root canal filling and desinfection may be required, oral bacteria can easily recolonize the root canal at any point, owing to a lack of tooth substance or a poorly adapted restoration [15-17].

If in the past the definitive obturation was postponed for a later session, during which the clinician waits to heal the periapical tissue, now it is recommended that the definitive obturation be applied in the same session as the root canal obturation, so that the risk of bacterial infiltration is diminished or even canceled.

Conclusions

Our study indicates that by damaging the interface between the hard dental structures and the coronal restoration, marginal microinfiltration is favored,. This can lead to both immediate and delayed consequences, such as the development of secondary caries and pulpal pathology. Additionally, it can compromise the quality of the root canal obturation by favoring the infiltration of the endodontic system from the corono-apical direction.

Incomplete or complete microcracks in the enamel were highlighted, including the dentin, as well as dehiscent areas that can be attributed to the polymerization contraction of the composite material from the interface area between the composite resin and dentin, as well as to the defects of procedure in applying the material.

Using endodontic microscopes, the quality of restoration of dental morphology can be appreciated in detail and the quality of marginal adaptations.

Presently, the issue of retreatment in the single session is recommended in most cases. This means that the endodontic treatment must be finished with a root canal filling, and the resin coronal restoration must also be applied in the same session.

We believe that it is necessary to extend the study on an appropriate number of extracted teeth, in order to obtain relevant results.

Incorrect coronal restoration can affect the prognosis of endodontic treatment.

Bibliography

  1. Tovares PB., et al. “Prevalence of apical periodontitis in teeth from french population”. Journal of Endodontics6 (2009): 810-813.
  2. Huumonen S., et al. “A Diagnostic value of computer tomography in retreatment of root in maxilar molars”. International Endodontic Journal 39 (2006): 827-833.
  3. Figini L., et al. “Single versus multiple visits for endodontic treatment of permanent teeth: a Cochrane systematic review”. Journal of Endodontics 34 (2008): 1041-1047.
  4. Reeh ES., et al. “Reduction in tooth stiffness as a result of endodontic and restorative procedures”. Journal of Endodontics 15 (1989): 512-516.
  5. Ricucci D., et al. “Bacterial status in rootfilled teeth exposed to the oral environment by loss of restoration and fracture or caries- a histobacteriological study of treated cases”. International Endodontic Journal 36 (2003): 787-802.
  6. Adolphi G., et al. “Direct resin composite restorations in vital versus root-filled posterior teeth: a con-trolled comparative long-term follow-up”. Operative Dentistry 32 (2007): 437-442.
  7. Pierrisnard L., et al. “Corono-radicular recon-struction of pulpless teeth: a mechanical study using finite elem-ent analysis”. Journal of Prosthetic Dentistry 88 (2002): 442-448.
  8. Vire DE. “Failure of endodontically treated teeth: classification and evaluation”. Journal of Endodontics 17 (1991): 338-342.
  9. SØrensen JA and Martinoff JT. “Intracoronal reinforcement and coronal coverage: a study of endodontically treated teeth”. Journal of Prosthetic Dentistry 51 (1984): 780-784.
  10. ElAyouti A., et al. “Influence of cuspcoverage on the fracture resistance of premolars with endodonticaccess cavities”. International Endodontic Journal 44 (2011): 543-549.
  11. Mondelli RFL., et al. “Fracture resistance of weakened teeth restored with condensable resin withand without cusp coverage”. Journal of Applied Oral Science 17 (2009): 161-165.
  12. Haapasalo M., et al. “Irrigation in endodontics”. British Dental Journal6 (2014): 299-303.
  13. Tabassum S and Khan FR. “Failure of endodontic treatment: the usual suspects”. European Journal of Dentistry 10.1 (2016): 144-147.
  14. AlHabdan AlHanouf Abdullah. “Review of Microleakage Evaluation Tools”. Journal of International Oral Health4 (2017): 141-145.
  15. Hajaj Tareq., et al. “Evaluation of Different Coronal Sealing Materials in the Endodontically Treated Teeth: An In Vitro Study”. Advances in Materials Science and Engineering (2021):
  16. A Mariani., et al. “Marginal micro-leakage of composite resin restorations with surface sealantand bonding agent application after finishing and polishing”. Journal of Physics: Conference Series 1073 (2018).
  17. T Rodig and M Hulsmann. “Restorative materials for thetemporary seal of the endodontic access cavity”. Journal of Endodontics2 (2008): 117-130.
